EnGenius - Indoor Wireless
The managed indoor Access Points of EnGenius Cloud and EnGenius Fit feature the most advanced Wi-Fi standard to expand user capacity and deployment options, providing flexible and reliable wireless connectivity.
EnGenius - The Power of Cloud, Now.
EnGenius Technologies is a cloud-driven leader within the connectivity space. Our mission for the past 20 years has been to deliver innovative world-class solutions for businesses of all sizes. Our team is committed to developing cutting-edge and simple-to-use designs to power your networks so you can focus on your business and customers.
As a technology leader, we are always pushing the boundaries of the possibilities in software engineering. We designed and built our cloud technology using our advanced AI engines to provide a unified platform for SD-WAN, network security, switching and wireless connectivity.
We are building a secure, cloud-centered ecosystem covering a variety of product categories, including Wireless Access Points, Network Switches, SD-WAN Gateways, and Power Distribution Units, designed to empower MSP providers with advanced feature sets, vertical market support, and ecosystem integration. With its easily scalable architecture and secured multi-tenant platform, EnGenius Cloud provides MSPs with a flexible and comprehensive solution to manage enterprise clients' networks.
Expertise Wave - Indoor Solutions - Wi-Fi 7
EnGenius Cloud and EnGenius Fit managed indoor Access Points are designed to provide high-performance wireless connectivity for various environments, including offices, retail spaces, and educational institutions. These solutions support the latest Wi-Fi standards, ensuring robust performance and scalability.
EnGenius Wi-Fi 7 - Model Comparison
Explore the technical specifications of EnGenius Wi-Fi 7 indoor access points, including the ECW520, ECW526, ECW516L, and ECW536. Each model offers unique features and capabilities to meet diverse networking needs.
| Cloud7 2x2x2 | Cloud7 2x2x2 | Cloud7 2x3x3 Lite | Cloud7 4x4x4 | |
|---|---|---|---|---|
| Specification | ECW520 | ECW526 | ECW516L | ECW536 |
| Datasheet | ||||
| Wi-Fi Standard | 11be | 11be | Wi-Fi 7 (11be) | 11be |
| Radio | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz & 6 GHz |
| Max. Data Rates (2.4 GHz) | 700 Mbps | 720 Mbps | 700 Mbps | 1,400 Mbps |
| Max. Data Rates (5 GHz) | 4,300 Mbps | 2,900 Mbps | 4,300 Mbps | 5,800 Mbps |
| Max. Data Rates (6 GHz) | 5,800 Mbps | 5,800 Mbps | 8,700 Mbps | 11,600 Mbps |
| Radio Chains | 2x2:2 | 2x2:2 | 2 x 2:2 (2.4GHz), 3 x 3:3 (5GHz & 6GHz) | 4 x 4:4 |
| Transmit Power on (2.4 GHz) | 23 dBm | 23 dBm | 22 dBm | 25 dBm |
| Transmit Power on (5 GHz) | 23 dBm | 22 dBm | 22 dBm | 24 dBm |
| Transmit Power on (6 GHz) | 20 dBm | 22 dBm | 22 dBm | 24 dBm |
| Antenna | 2.4 GHz: 2 x 6 dBi Omni; 5 GHz: 2 x 6 dBi Omni; 6 GHz: 2 x 6 dBi Omni; | 2 x 5 dBi Omni (2.4 GHz); 2 x 6 dBi Omni (5 GHz); 2 x 6 dBi Omni (6 GHz); | 2 x 5 dBi (2.4 GHz); 3 x 5 dBi (5 GHz); 3 x 5 dBi (6 GHz) | 4 x 5 dBi Omni (2.4 GHz); 4 x 6 dBi Omni (5 GHz); 4 x 5 dBi Omni (6 GHz); |
| Power-over-Ethernet | 802.3at | 802.3at | 802.3at | 802.3bt |
| Scanning Radio | - | - | - | - |
| BLE | - | - | - | - |
| Power Consumption (Peak) | 25.4 W | - | - | - |
| Ethernet Ports | 1x 2.5GE PoE+port | 1x 10GE PoE+port | 1x 2.5GE PoE+ port | 1x 10GE PoE++port / 1x 10GE port |
| Mounting Type | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling |
| Dimensions | 158 x 158 x 35.8 mm | 190 x 190 x 39.5 mm | 205 x 205 x 33 mm | 230 x 230 x 39.5mm |
| Mesh Technology | Yes | Yes | Yes | Yes |
| Cloud To-Go app | Yes | Yes | Yes | Yes |
| EnWiFi app | - | - | - | - |
Expertise Wave - Indoor Solutions - Wi-Fi 6E
EnGenius Wi-Fi 6E indoor access points deliver ultra-fast wireless speeds, lower latency, and increased capacity by utilizing the newly available 6 GHz band. This enables more simultaneous connections, reduced interference, and enhanced performance for demanding environments such as offices, schools, and retail spaces. With advanced security features and cloud management, EnGenius Wi-Fi 6E solutions ensure reliable connectivity and simplified network administration.
EnGenius Wi-Fi 6E - Model Comparison
Compare the technical specifications of EnGenius Wi-Fi 6E indoor access points: ECW336, ECW230S, ECW230, and ECW220S. Find the right solution for your wireless needs.
| Cloud6E 4x4x4 | Cloud6 4x4 S | Cloud6 4x4 | Cloud6 2x2 S | Cloud6 2x2 | Cloud5 2x2 | |
|---|---|---|---|---|---|---|
| Model Number | ECW336 | ECW230S | ECW230 | ECW220S | ECW220 | ECW120 |
| Datasheet | ||||||
| Wi-Fi Standard | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | 11ac Wave 2 |
| Radio | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz |
| Max. Data Rates (2.4 GHz) | 1,200 Mbps | 1,200 Mbps | 1,200 Mbps | 600 Mbps | 600 Mbps | 400 Mbps |
| Max. Data Rates (5 GHz) | 2,400 Mbps | 2,400 Mbps | 2,400 Mbps | 1,200 Mbps | 1,200 Mbps | 867 Mbps |
| Max. Data Rates (6 GHz) | 4,800 Mbps | - | - | - | - | - |
| Radio Chains | 4 x 4:4 | 4 x 4:4 | 4 x 4:4 | 2 x 2:2 | 2 x 2:2 | 2 x 2:2 |
| Transmit Power on (2.4 GHz) | 23 dBm | 23 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm |
| Transmit Power on (5 GHz) | 23 dBm | 23 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm |
| Transmit Power on (6 GHz) | 23 dBm | - | - | - | - | - |
| Antenna | 4 x 5 dBi Omni (2.4 GHz); 4 x 6 dBi Omni (5 GHz); 4 x 5 dBi Omni (6 GHz); | 4 x 5 dBi Omni (2.4 GHz); 4 x 6 dBi Omni (5 GHz); | 4 x 5 dBi Omni (2.4 GHz); 4 x 6 dBi Omni (5 GHz); | 2 x 4 dBi Omni (2.4 GHz); 2 x 5 dBi Omni (5 GHz); | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 2 x 5 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) |
| Power-over-Ethernet | 802.3at | 802.3af/at | 802.3af/at | 802.3af/at | 802.3af | 802.3af |
| Scanning Radio | - | Yes | Yes | Yes | - | - |
| BLE | - | Yes | Yes | Yes | - | - |
| Power Consumption (Peak) | - | - | - | - | - | - |
| Ethernet Ports | 1x 5GE PoE+ port | 1x 2.5GE PoE+ port | 1x 2.5GE PoE+ port | 1x GE PoE+ port | 1x GE PoE port | 1x GE PoE port |
| Mounting Type | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling |
| Dimensions | 205 x 205 x 33 mm | 205 x 205 x 33.2 mm | 205 x 205 x 33.2 mm | 160 x 160 x 33 mm | 160 x 160 x 33 mm | 161.5 x 161.5 x 41.6 mm |
| Mesh Technology | Yes | Yes | Yes | Yes | Yes | Yes |
Expertise Wave - Indoor Solutions - Wi-Fi 6
EnGenius Wi-Fi 6 indoor access points leverage the latest 802.11ax technology to deliver faster speeds, higher capacity, and improved efficiency for modern wireless environments. With features like OFDMA, MU-MIMO, and enhanced security, these access points support more simultaneous users and devices, reduce network congestion, and provide reliable connectivity for offices, schools, and retail spaces. EnGenius Wi-Fi 6 solutions are managed via the cloud, enabling simplified deployment, monitoring, and maintenance.
EnGenius Wi-Fi 6 Indoor APs - Model Comparison
Compare the technical specifications of EnGenius Wi-Fi 6 indoor access points: Cloud6 2x2 Lite, Cloud6 4x4 Lite, Cloud7 2x3x3 Lite, and Cloud6 2x2.
| Model | Cloud6 2x2 Lite | Cloud6 4x4 Lite | Cloud7 2x3x3 Lite | Cloud6 2x2 | Cloud6 4x4 |
|---|---|---|---|---|---|
| Model Number | ECW210L | ECW212L | ECW516L | ECW220 | ECW230 |
| Wi-Fi Standard | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 7 (11be) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) |
| Radio | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz |
| Max. Data Rates (2.4 GHz) | 600 Mbps | 1200 Mbps | 700 Mbps | 600 Mbps | 1200 Mbps |
| Max. Data Rates (5 GHz) | 2400 Mbps | 2400 Mbps | 4300 Mbps | 1200 Mbps | 2400 Mbps |
| Max. Data Rates (6 GHz) | - | - | 8700 Mbps | - | - |
| Radio Chains | 2 x 2:2 | 4 x 4:4 | 2 x 2:2 (2.4GHz), 3 x 3:3 (5GHz & 6GHz) | 2 x 2:2 | 4 x 4:4 |
| Transmit Power on (2.4 GHz) | 21 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm |
| Transmit Power on (5 GHz) | 21 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm |
| Transmit Power on (6 GHz) | - | - | 22 dBm | - | - |
| Antenna | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 4 x 5 dBi (2.4 GHz); 4 x 5 dBi (5 GHz) | 2 x 5 dBi (2.4 GHz); 3 x 5 dBi (5 GHz); 3 x 5 dBi (6 GHz) | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 4 x 5 dBi (2.4 GHz); 4 x 6 dBi (5 GHz) |
| Power-over-Ethernet | 802.3af | 802.3at | 802.3at | 802.3af | 802.3af/at |
| Scanning Radio | - | - | - | - | - |
| BLE | - | - | - | - | - |
| Power Consumption (Peak) | - | - | - | - | - |
| Ethernet Ports | 1x GE PoE port | 1x 2.5GE PoE+ port | 1x 2.5GE PoE+ port | 1x GE PoE port | 1x 2.5GE PoE+ port |
| Mounting Type | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling | Wall/ Ceiling |
| Dimensions | 160 x 160 x 30 mm | 205 x 205 x 33 mm | 205 x 205 x 33 mm | 160 x 160 x 33 mm | 205 x 205 x 33.2 mm |
| Mesh Technology | Yes | Yes | Yes | Yes | Yes |
| Cloud To-Go app | Yes | Yes | Yes | Yes | Yes |
| EnWiFi app | - | - | - | - | - |
Indoor Wireless Solutions from Expertise wave in Saudi Arabia
Expertise Wave offers a comprehensive range of indoor wireless solutions in Saudi Arabia, including EnGenius Wi-Fi 6 and Wi-Fi 6E access points. These solutions are designed to provide high-speed connectivity,
robust security, and seamless performance for various indoor environments such as offices, schools, and retail spaces. With advanced features like cloud management and mesh technology, Expertise Wave ensures reliable and efficient wireless networks tailored to meet the specific needs of businesses in the region.
Expertise Wave - Indoor Solutions - Security
EnGenius security solutions for indoor wireless environments include advanced features such as intrusion detection, secure guest access, and robust encryption protocols. These solutions are designed to protect sensitive data and ensure compliance with industry standards, making them ideal for businesses that prioritize security in their wireless networks.
EnGenius Wi-Fi Indoor APs Security - Model Comparison
Compare the technical specifications of EnGenius Wi-Fi indoor access points Security: Cloud6 4x4 S, Cloud6E 4x4x4, Cloud6 4x4, Cloud6 2x2 S, Cloud6 2x2, Cloud5 2x2, Cloud5 2x2 Wallplate.
| Model Number | ECW230S | ECW336 | ECW230 | ECW220S | ECW220 | ECW120 | ECW115 |
|---|---|---|---|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | Wi-Fi 6 (11ax) | 11ac Wave 2 | 11ac Wave 2 |
| Radio | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz & 6 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz | 2.4 GHz & 5 GHz |
| Max. Data Rates (2.4 GHz) | 1,200 Mbps | 1,200 Mbps | 1,200 Mbps | 600 Mbps | 600 Mbps | 400 Mbps | 400 Mbps |
| Max. Data Rates (5 GHz) | 2,400 Mbps | 2,400 Mbps | 2,400 Mbps | 1,200 Mbps | 1,200 Mbps | 867 Mbps | 867 Mbps |
| Max. Data Rates (6 GHz) | - | 4,800 Mbps | - | - | - | - | - |
| Radio Chains | 4 x 4:4 | 4 x 4:4 | 4 x 4:4 | 2 x 2:2 | 2 x 2:2 | 2 x 2:2 | 2 x 2:2 |
| Transmit Power on (2.4 GHz) | 23 dBm | 23 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm | 17 dBm |
| Transmit Power on (5 GHz) | 23 dBm | 23 dBm | 23 dBm | 22 dBm | 22 dBm | 23 dBm | 17 dBm |
| Transmit Power on (6 GHz) | - | 23 dBm | - | - | - | - | - |
| Antenna | 4 x 5 dBi (2.4 GHz); 4 x 6 dBi (5 GHz) | 4 x 5 dBi Omni (2.4 GHz); 4 x 6 dBi Omni (5 GHz); 4 x 5 dBi Omni (6 GHz) | 4 x 5 dBi (2.4 GHz); 4 x 6 dBi (5 GHz) | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 2 x 5 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) | 2 x 4 dBi (2.4 GHz); 2 x 5 dBi (5 GHz) |
| Power-over-Ethernet | 802.3af/at | 802.3at | 802.3af/at | 802.3af/at | 802.3af | 802.3af | 802.3af/at |
| Scanning Radio | Yes | - | - | Yes | - | - | - |
| BLE | Yes | - | - | Yes | - | - | - |
| Power Consumption (Peak) | - | - | - | - | - | - | - |
| Ethernet Ports | 1x 2.5GE PoE+ port | 1x 5GE PoE+ port | 1x 2.5GE PoE+ port | 1x GE PoE+ port | 1x GE PoE port | 1x GE PoE port | 2x GE PoE+ ports ; 1x GE PSE Out port |
| Mounting Type | Wall / Ceiling | Wall / Ceiling | Wall / Ceiling | Wall / Ceiling | Wall / Ceiling | Wall / Ceiling | Wall / Ceiling |
| Dimensions | 205 x 205 x 33.2 mm | 205 x 205 x 33 mm | 205 x 205 x 33.2 mm | 160 x 160 x 33 mm | 160 x 160 x 33 mm | 161.5 x 161.5 x 41.6 mm | 140 x 90 x 40 mm |
| Mesh Technology | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Cloud To-Go app | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| EnWiFi app | - | - | - | - | - | - | - |
